Build High-Performing Node.js Applications using Streams

Overview

Streams are not a concept unique to Node.js. They were introduced in the Unix operating system decades ago.

If you learn to work with these streams of bits, you'll be able to build performant and valuable applications. For example, think of when you watch a video on YouTube. You don't have to wait until the full video downloads. Once a small amount buffers, it starts to play, and the rest keeps on downloading as you watch.

Buffer represents a fixed-size chunk of memory (can't be resized) allocated outside of the V8 JavaScript engine. It is where streams of data are passed to form a small chunk that are later sent to the client. Don't worry, we'll learn about this while doing an example.

A quick, small word of warning: You likely won't encounter many situations where streams are a necessity, and a stream-based approach can increase the complexity of your application. Make sure you confirm that the benefits of using streams outweigh the complexity they'll bring.

What are Streams?

According to Node.js official documentation, stream is an abstract interface for working with streaming data in Node.js.

A key thing of streams is that instead of loading up a big file in memory or a big array of data, you are consuming them as this data is loaded or produced. So by processing it chunk-by-chunk or item-by-item, you can actually process a huge amount of data with constant memory… Which is great, for example, to ingest a file that is a size of a gigabyte, or ten gigabytes, or a terabyte even, whatever… Because we can just process them chunk by chunk, and not allocating all this memory that we cannot fit on our current machine.

Why Streams?

Streams basically provide two major advantages over using other data handling methods:

• Memory efficiency: you don't need to load large amounts of data in memory before you are able to process it.
• Time efficiency: it takes way less time to start processing data, since you can start processing as soon as you have it, rather than waiting till the whole data payload is available.

Before we dive into building applications, it's important to understand the features provided by the Node.js stream module.

Types of Node.js Streams

Node.js streams provides four types of streams:

• Readable Streams
• Writable Streams
• Duplex Streams
• Transform Streams

See the official Node.js docs for more detail on the types of streams.

Let's look at each stream type at a high level.

Readable Streams

A readable stream can read data from a particular data source, most commonly, from a file system. Other common use of readable streams in Node.js applications is process.stdin - To read user input via stdin in a terminal application.

Writable Streams

You use writable streams to write data from an application to a specific destination, for example, a file. process.stdout can be used to write data to standard output and is used internally by console.log.

Duplex Streams

A duplex stream is a combination of both readable and writable streams. It provides the capability to write data to a particular destination and read data from a source. The most common example of a duplex stream is net.Socket, used to read and write data to and from a socket.

It's important to know that readable and writable sides operate independently from one another in a duplex stream. The data does not flow from one side to the other.

Transform Streams

A transform stream is slightly similar to a duplex stream, but the readable side is connected to the writable side in a transform stream.

Read Data From Readable Node.js Streams

Once a readable stream is connected to a source that generates data (e.g., a file), there are a few ways to read data through the stream.

First, let's create a sample text file named myfile.txt, with 85 bytes of 'lorem ipsum' text:

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Curabitur nec mauris turpis.

The most common way to read data from a readable stream is by listening to 'data' events emitted by the stream. The following program demonstrates this approach:

const fs = require('fs')
const readable = fs.createReadStream('./myfile.txt', { highWaterMark: 20 })

readable.on('data', (chunk) => {
  console.log(`Read ${chunk.length} bytes\n"${chunk.toString()}"\n`)
})

The highWaterMark property, passed as an option to fs.createReadStream, determines how much data buffers inside the stream. The data is then flushed to the reading mechanism (in this case, our 'data' handler). By default, readable fs streams have their highWaterMark set to 64kB. We deliberately override this to 20 bytes to trigger multiple 'data' events.

If you run the above program, it will read 85 bytes from myfile.txt in five iterations. You will see the following output in the console:

Read 20 bytes
"Lorem ipsum dolor si"

Read 20 bytes
"t amet, consectetur "

Read 20 bytes
"adipiscing elit. Cur"

Read 20 bytes
"abitur nec mauris tu"

Read 5 bytes
"rpis."

State of a Readable Node.js Stream

When a listener is attached to a readable stream's 'data' events, the stream switches to a 'flowing' state (unless it is explicitly paused). You can inspect the stream's flowing state using the stream object's readableFlowing property.

We can demonstrate this using a slightly modified version of our previous example with the 'data' handler:

const fs = require('fs')
const readable = fs.createReadStream('./myfile.txt', { highWaterMark: 20 })

let bytesRead = 0

console.log(`before attaching 'data' handler. is flowing: ${readable.readableFlowing}`)
readable.on('data', (chunk) => {
  console.log(`Read ${chunk.length} bytes`)
  bytesRead += chunk.length

  // Pause the readable stream after reading 60 bytes from it.
  if (bytesRead === 60) {
    readable.pause()
    console.log(`after pause() call. is flowing: ${readable.readableFlowing}`)

    // resume the stream after waiting for 1s.
    setTimeout(() => {
      readable.resume()
      console.log(`after resume() call. is flowing: ${readable.readableFlowing}`)
    }, 1000)
  }
})
console.log(`after attaching 'data' handler. is flowing: ${readable.readableFlowing}`)

In this example, we read from myfile.txt via a readable stream, but we temporarily 'pause' the data flow for 1s after reading 60 bytes from the file. We also log the value of the readableFlowing property at different times to understand how it changes.

If you run the above program, you will get the following output:

before attaching 'data' handler. is flowing: null
after attaching 'data' handler. is flowing: true
Read 20 bytes
Read 20 bytes
Read 20 bytes
after pause() call. is flowing: false
after resume() call. is flowing: true
Read 20 bytes
Read 5 bytes

We can explain the output as follows:

• When our program starts, readableFlowing has the value null because we don't provide any mechanism of consuming from the stream.
• After the 'data' handler is attached, the readable stream changes to 'flowing' mode, and readableFlowing changes to true.
• Once 60 bytes are read, the stream is 'paused' by calling pause(), which, in turn, changes readableFlowing to false.
• After waiting for 1s, the stream switches to 'flowing' mode again by calling resume(), changing readableFlowing to true. The rest of the file content then flows through the stream.

Processing Large Amounts of Data with Node.js

Thanks to streams, applications do not have to keep large blobs of information in memory: small chunks of data can be processed as they are received.

In this section, let's combine different streams to build a real-life application that can handle large amounts of data. We'll use a small utility program that generates an SHA-256 of a given file.

But first, let's create a large 4GB dummy file for testing. You can do this using a small shell command, as follows:

• On macOS: mkfile -n 4g 4gb_file
• On Linux: xfs_mkfile 4096m 4gb_file

After creating our dummy 4gb_file, let's generate the SHA-256 hash of the file without using the stream module:

const fs = require('fs')
const crypto = require('crypto')

fs.readFile('./4gb_file', (readErr, data) => {
  if (readErr) return console.log(readErr)
  const hash = crypto.createHash('sha256').update(data).digest('base64')
  fs.writeFile('./checksum.txt', hash, (writeErr) => {
    writeErr && console.error(err)
  })
})

If you run the above code, you may get the following error:

RangeError [ERR_FS_FILE_TOO_LARGE]: File size (4294967296) is greater than 2 GB
  at FSReqCallback.readFileAfterStat [as oncomplete] (fs.js:294:11) {
  code: 'ERR_FS_FILE_TOO_LARGE'
}

The above error occurs because the JavaScript runtime cannot handle arbitrarily large buffers. The max size of a buffer that the runtime can handle depends on your operating system architecture.

Even if we didn't see the above error, keeping large files in memory is problematic. The physical memory we have available will restrict the amount of memory our application can use. High memory usage can also cause poor application performance in terms of CPU usage, as garbage collection becomes expensive.

Reduce Your App's Memory Footprint Using Streams

Now, let's look at how we can modify our application to use streams and avoid encountering this error:

const fs = require('fs')
const crypto = require('crypto')
const { pipeline } = require('stream')

const hashStream = crypto.createHash('sha256')
hashStream.setEncoding('base64')

const inputStream = fs.createReadStream('./4gb_file')
const outputStream = fs.createWriteStream('./checksum.txt')

pipeline(inputStream, hashStream, outputStream, (err) => {
  err && console.error(err)
})

In this example, we use the streaming approach provided by the crypto.createHash function. It returns a "transform stream" object hashStream, generating hashes for arbitrarily large files.

To feed the file content into this transform stream, we have created a readable stream — inputStream — to 4gb_file using fs.createReadStream. We pipe the output from the hashStream transform stream to the writable outputStream and the checksum.txt, created using fs.createWriteStream.

If you run the above application, you will see that the checksum.txt file populates with the SHA-256 hash of our 4GB file.

Using pipeline() vs pipe() for Streams

In our previous example, we used the pipeline function to connect multiple streams. An alternative common approach is to use the .pipe() function, as shown below:

inputStream.pipe(hashStream).pipe(outputStream)

However, using .pipe() in production applications is not recommended for several reasons. If one of the piped streams is closed or throws an error, pipe() will not automatically destroy the connected streams. This can cause memory leaks in applications. Also, pipe() does not automatically forward errors across streams to be handled in one place.

pipeline() was introduced to cater for these problems, so it's recommended you use pipeline() instead of pipe() to connect multiple streams. It also accepts a callback function as the last parameter. Any forwarded errors from any of the piped streams will call the callback, so it's easier to handle errors for all streams in one place.

Wrap Up

Using streams in Node.js helps us build performant applications that can handle large amounts of data.

In this article, we covered:

• What are streams and why to use it.
• The four types of Node.js streams (readable, writable, duplex, and transform streams).
• How you can read data from readable Node.js streams by listening to 'data' events.
• Reducing the memory footprint of your applications by using pipeline to connect multiple streams.

I'd encourage you to read the official Node.js stream documentation to learn more and to explore more advanced use cases of streams out there.

Happy coding!
